HZKS-3 ASTM D92 Open Cup Flash Point Tester

Flash Point is the lowest temperature at which a liquid can form an ignitable mixture with air near its surface. The lower the flash point, the easier it is to ignite the material. Nowadays, the term "flash point" is used to refer to non-volatile or flammable substances, regardless of whether they are highly volatile or flammable. It has become one of the most important parameters for the transportation, storage, operation, and safety management of petroleum products.

Send Inquiry

HZKS-3 Open Cup Flash Point Tester

HZKS-3 ASTM D92 Open Cup Flash Point Tester

Products Description

I. Function Overview

The HZKS-3 Automatic Open Flash Point Tester determines the open flash point of petroleum products. It complies with major international standards:

People's Republic of China (GB/T 267-88, GB/T 3536-2008)

European Standard

ASTM D92

II. Instrument Features

The HZKS-3 integrates advanced technology into a user-friendly design, featuring:

Modular Flexibility:

Single main unit controls multiple furnaces (open/closed)

Freely interchangeable for efficiency and cost savings

Precision Control:

High-speed processor + high-precision A/D

Adaptive PID control for standard curve temperature

Automatic atmospheric pressure correction

Safety & Automation:

Full automation: detection, cover, ignition, alarm, cooling, print

Auto ignition

Out-of-range auto stop + alarm

User Interface:

320×240 graphical LCD, English interface

Full-screen touch (no keyboard)

Screen saver

Data & Output:

256 timestamped records

Integrated thermal micro-printer (offline printing)

RS232 for printer or PC

Open Cup Flash Point Tester
III.Technical Parameters

Item	Specification
Temperature Measuring Range	-59.9°C～399.9°C
Temperature Control Range	Room temperature～350°C
Repeatability	≤150℃：3℃;＞150℃：5℃
Resolution	0.1°C
Precision	0.50%
Temperature Sensor	Platinum Resistor(PT100)
Flash Fire Sensor	Ion detection ring
Ambient Temperature	0 ~ 40°C
Relative Humidity	≤ 85% RH
Power Supply	AC220V ± 20% ; 50HZ ± 10%
Power Consumption	approx 400W
Overall Dimension	440×280×290(mm)
Instrument Weight	14kg
