50kV VLF High Voltage Cable Tester
Huazheng HZDP-50kV 50kV VLF High Voltage Cable Tester In the ever-evolving world of electrical engineering, safety and reliability are paramount. Introducing the VLF Hipot Tester—a cutting-edge solution designed to meet the rigorous demands of high-voltage testing. This innovative device is engineered to ensure the integrity of insulation in cables, transformers, and other electrical equipment, making it an essential tool for professionals in the field.
50kV VLF High Voltage Cable Tester
Products Description
The 50kV VLF High Voltage Cable Tester is used for testing the withstand voltage and insulation performance of medium and high voltage cables. It accurately detects insulation defects under low power conditions using an ultra-low frequency high voltage method.
Customizable Options
Vlf High Voltage Cable Tester Parameter
|
Model |
Rated voltage |
Carrying capacity |
Power source Safety tube |
Product structure and weight |
|
|
|
30/1.1 |
30kV (Peak value) |
0.1Hz,≤0.5µF |
10A |
Controller：4㎏ Voltage booster：20㎏ |
|
0.05Hz,≤1.1µF |
||||
|
0.02Hz,≤2.2µF |
||||
|
0.01Hz,≤5.5µF |
||||
|
40/1.1 |
40kV (Peak value) |
0.1Hz,≤0.5µF |
10A |
Controller：4㎏ Voltage booster：20㎏ |
|
0.05Hz,≤1.1µF |
||||
|
0.02Hz,≤2.2µF |
||||
|
0.01Hz,≤5.5µF |
||||
|
50/1.1 |
50kV (Peak value) |
0.1Hz,≤0.5µF |
15A |
Controller：4㎏ Voltage booster：40㎏ |
|
0.05Hz,≤1.1µF |
||||
|
0.02Hz,≤2.2µF |
||||
|
0.01Hz,≤5.5µF |
||||
|
60/1.1 |
60kV (Peak value) |
0.1Hz,≤0.5µF |
15A |
Controller：4㎏ Voltage booster：50㎏ |
|
0.05Hz,≤1.1µF |
||||
|
0.02Hz,≤2.2µF |
||||
|
0.01Hz,≤5.5µF |
||||
|
80/1.1 |
80kV (Peak value) |
0.1Hz,≤0.5µF |
15A |
Controller：4㎏ Voltage booster：50㎏ |
|
0.05Hz,≤1.1µF |
||||
|
0.02Hz,≤2.2µF |
||||
|
0.01Hz,≤5.5µF |
||||
|
90/1.1 |
90kV (Peak value) |
0.1Hz,≤0.5µF |
15A |
Controller：4㎏ Voltage booster：55㎏ |
|
0.05Hz,≤1.1µF |
||||
|
0.02Hz,≤2.2µF |
||||
|
0.01Hz,≤5.5µF |
FAQ
Q: 1. When can I get a price quote?
A: You can contact us online or submit an inquiry form. We typically provide a quotation within 24 hours after receiving your request.
Q: 2. How do you handle after-sales service for overseas customers?
A: We provide comprehensive after-sales support, including:
12-month warranty (see details below)
Online technical support for remote troubleshooting
Fast shipment of replacement parts when needed
On-site technical support (available for critical issues upon request)
Q: 3. What is the warranty period?
A: Our standard warranty period is 12 months. During this time, we provide:
Free technical support
Replacement of parts caused by manufacturing defects
Customized solutions based on your specific issue
