HZJY-5K-I 5kV Insulation Resistance Test Device
Products Description
Key Features
5 Test Voltages Range: 500V/1000V/2500V/5000V, max. insulation resistance 5TΩ@5kV
Safety Compliance: Meets IEC 61010-1 (CAT.IV 600V), IEC 61326 (EMC), IP64 rating
Core Functions
Auto-calculates Polarization Index (PI) & Dielectric Absorption Ratio (DAR)
Leakage current & capacitance testing (20μF range, ±15%+0.03μF accuracy)
Anti-interference: Maintains accuracy with ≤2mA noise current
Protection Systems
Adjustable short-circuit current (2–5mA, customizable to 10mA)
Auto-capacitor discharge (5000V→10V: 0.5s/μF)
Fuse failure alert
Power Options
Li-ion battery: 16.8V, 6hr runtime (5000V@100MΩ)
AC power: 220V±10%, 50/60Hz, 20VA
User Interface
Insulation resistance analog bar display
Digital filtering (suppresses external interference)
Technical Specifications
| Parameter | Value | |||
|---|---|---|---|---|
| Dimensions | 26cm × 20cm × 16cm | |||
| Weight | 3kg | |||
| Voltage Accuracy | 100%–110% of nominal value | |||
| Current Measurement | 10mA range, ±5%+0.2nA accuracy | |||
| Insulation Resistance Accuracy | (23±5°C, RH 45–75%) | |||
| Test Voltage | 500V | 1000V | 2500V | 5000V |
| Accuracy/Range | ||||
| ±5% | 100kΩ–10GΩ | 100kΩ–20GΩ | 100kΩ–100GΩ | 100kΩ–100GΩ |
| ±20% | 10G–100GΩ | 20G–200GΩ | 100G–1TΩ | 100G–1TΩ |
Packing List
|
No. |
Item |
Qty |
|
1 |
High-voltage silicone test line (one red, one green, one black) |
3 |
|
2 |
AC 220V power line |
1 |
FAQ
1. When can I get a price quote?
You can contact us online or submit an inquiry. We typically provide a quote within 24 hours after receiving your request.
2. How do you handle after-sale service for overseas customers?
For issues occurring with our products, we offer:
12-month warranty coverage (see details below).
Online technical guidance to troubleshoot problems remotely.
Replacement parts shipped promptly based on your needs.
On-site support (if required): Our engineers can travel abroad to resolve critical issues.
3. What is the warranty period?
Our standard warranty period is 12 months (1 year).
