HZ-3310B 3 Phase 10A Transformer Winding Resistance Meter

HZ-3310B 3 Phase Transformer Winding Resistance Meter Safety Measures Must read this manual carefully before using the tester; The tester operator should understand the common knowledge on general electrical devices or instruments; The tester can be used indoors and outdoors, but it should be...

Send Inquiry

HZ-3310B 3 Phase Transformer Winding Resistance Meter

Products Description

Functional Characteristics

Flexible Current Selection

The tester allows selection of the corresponding output current value based on the test object. It is primarily suitable for measuring inductive DC resistance in transformers.

Large Transformer Testing

For large transformers with a five-leg core and low-voltage windings connected in delta, the tester can perform tests in HV & LV series excitation mode. The magnetic augmentation circuit of the windings is automatically connected within the tester, enabling quick and accurate measurement of low-voltage winding DC resistance.

Three-Phase Test Function

The tester features a three-phase test function to synchronously measure the three-phase DC resistance of star-connected windings and automatically calculate the three-phase unbalance rate, significantly reducing measurement time and improving test efficiency. Its phase-by-phase test function is also applicable to transformers with YN and D (Y) connections.

Winding Material Setting

The winding material can be set according to the transformer's winding material (e.g., copper or aluminum) to distinguish the temperature coefficient conversion for different materials.

Neutral Point Lead Resistance Detection

The tester is equipped with a detection function for the neutral point lead resistance of YN-connected transformer windings, ensuring three-phase test data more closely match single-phase test values.

Protection and Safety

A complete protection circuit and audible discharge alarm provide clear discharge indication and reduce the risk of misoperation.

Display and Interface

7-inch color touch screen for clear real-time display of test data

Chinese and English operation interfaces, configurable according to user requirements

Communication and Data Transfer

RS232 communication port for transmitting test data to a background computer with host control software

USB port for transferring test data to a U disk

Data Management

Built-in calendar and clock

Storage (up to 100 groups of test data), review, and printing functions

Parameter Settings

Comprehensive parameter settings include test windings, tapping positions, test phases, tested sample temperature, conversion temperature, and other transformer-related parameters.

Technical Indicators

Item	Specification
Output current	Three‑phase test: 5A+5A; 1A+1A; 200mA+200mA; 20mA+20mASingle‑phase test: 10A; 5A; 1A; 200mA; 20mA
Measurement range	Three‑phase test:5A+5A: 2 mΩ～1.2 Ω1A+1A: 10 mΩ～6 Ω200mA+200mA: 100 mΩ～30 Ω20mA+20mA: 10 Ω～200 ΩSingle‑phase test:10A: 1 mΩ～2 Ω5A: 2 mΩ～4 Ω1A: 10 mΩ～20 Ω200mA: 100 mΩ～100 Ω20mA: 10 Ω～20 kΩ
Accuracy	±(0.2%+2 digits)
Minimum resolution	0.1 μΩ
Operating temperature	-10～40 °C
